The Yamaha VXC3F is a low-profile, full-range ceiling speaker designed for commercial spaces, particularly for background music (BGM) reproduction. It is part of Yamaha's VXC Series "F model" lineup, which focuses on easy installation and high-quality sound for a variety of environments.

Key Features:

• Optimized for Background Music (BGM): The speaker is specifically tuned to provide clear, natural music reproduction at all volume levels, without the midrange distortion often found in other speakers of this type.

• Low-Profile Design: Its shallow depth allows for installation in ceilings with limited space.

• Versatile Connectivity: The VXC3F supports both high-impedance (Hi-Z) and low-impedance (Lo-Z) connections, with an easily accessible tap switch on the baffle.

  • High-Impedance (70V/100V line):

    • 100V: 15W, 7.5W, 3.8W taps

    • 70V: 15W, 7.5W, 3.8W, 1.9W taps

  • Low-Impedance: 8Ω nominal impedance

• Ease of Installation:

  • Built-in Carrying Band: A flexible band makes the speaker easy to carry and handle during installation.

  • Anti-Drop Tab Mechanism: This feature provides a secure temporary hold, allowing for safe and efficient installation.

  • Double-threaded Speaker Clamp Screws: These screws allow for faster tightening of the clamps.

  • Magnetic Grille: The included grille is held in place by magnets, making it easy to attach and remove.

• Aesthetic and Durability:

  • Paintable Grille: The grille can be painted to match any interior décor.

  • Available in Two Colors: The VXC3F comes in black, while the VXC3FW is white.

  • Protective Circuit: It features a full-range power limiting circuit to protect the network and transducers from damage.

Technical Specifications:

• Speaker Type: Full-range, Bass reflex

• Components: 3.5” full-range unit

• Frequency Range: 71 Hz – 20 kHz (-10 dB)

• Nominal Coverage: 140° conical

• Power Rating:

  • NOISE: 20 W

  • PGM: 40 W

  • PEAK: 80 W

• SPL:

  • Sensitivity (1W, 1m on axis): 87 dB SPL

  • Peak (Calculated): 106 dB SPL

• Dimensions:

  • Diameter: 285 mm (11-1/4")

  • Depth: 112 mm (4-7/16")

• Cutout Size: Ø247 mm (Ø9-3/4")

• Net Weight: 2.5 kg (5.5 lbs)

• Included Accessories: O-ring, Tile Rail, Cutout Template, Euro Block (4pin), and Terminal Cover.

• Certifications: UL1480, NFPA70, CE, EAC, RoHS. Some models (VXC3F-VA) are also EN54-24 compliant.

Harga tertera untuk : 1 Pair
